Home /Products/NTC Thermistor/SOCAY High Accuracy Temperature Sensor NTC Thermistor MF72-SCN8D-15 8ohm 15mm

SOCAY High Accuracy Temperature Sensor NTC Thermistor MF72-SCN8D-15 8ohm 15mm

2000PCS / 1000PCS
MOQ
Negotiable
Price
SOCAY High Accuracy Temperature Sensor NTC Thermistor MF72-SCN8D-15 8ohm 15mm
Features Gallery Product Description Request A Quote
Features
Specifications
Resistance At 25℃ ±20%: 8Ω
Max. Permissible Working Current: 5A
Resistance Under Load (mΩ): 178mΩ
Dissipation Factor(mW/℃）: 20mW/℃
Thermal Time Constant（Sec.)_）: 80Sec.
Maximum Permissible Capacitance @240Vac(uF): 470uF
Body Size: 15mm
Operating Temperature Range: -40~+200℃
Storage Temperature Range: -10 To +40 ℃
Highlight:

8ohm NTC Thermistor

,

15mm NTC Thermistor

,

MF72-SCN8D-15
Basic Infomation
Place of Origin: Shenzhen,Guangdong,China
Brand Name: SOCAY
Certification: UL,REACH,ROHS,ISO
Model Number: MF72-SCN8D-15
Document: Product Brochure PDF
Payment & Shipping Terms
Packaging Details: Bulk
Delivery Time: 5-7 days
Payment Terms: T/T, Western Union, MoneyGram,
Supply Ability: 250,000PCS Per Month
Product Description

SOCAY High Accuracy Temperature Sensor NTC Thermistor MF72-SCN8D-15 3ohm 15mm



DATASHEET:  MF72-SCN8D-15_v2105.1.pdf







Model number
MF72-SCN3D-15
Color
Black and Others
Max State Current
6%
Rated Resistor
-55 to 125C
Quality
Standard
RoHS Compliant
Service
One Stop BOM Service



SOCAY High Accuracy Temperature Sensor NTC Thermistor MF72-SCN8D-15 8ohm 15mm 0



SOCAY High Accuracy Temperature Sensor NTC Thermistor MF72-SCN8D-15 8ohm 15mm 1

Part Namin Code:



(1) MF72: MF72 Series.

(2) SCN: Socay NTC.

(3) 8D: Zero Power Resistance at 25℃(R25): 8=8Ω.

(4) Body Size: 15=Ф15mm.



Electrical Arguments:



Part Number Resistance
at 25℃
±20%		 Max. Permissible
Working
Current		 Resistance
under Load
(mΩ)		 Dissipation
Factor		 Thermal
Time
Constant		 Maximum
permissible
capacitance
@240Vac
R25(Ω) Imax(A) (mΩ) δ(mW/℃) τ(Sec.) C(uF)
MF72-SCN8D-15 8 5 178 20 80 470



Maximum Power Rating(Pmax):



SOCAY High Accuracy Temperature Sensor NTC Thermistor MF72-SCN8D-15 8ohm 15mm 2

Product Appearance :

SOCAY High Accuracy Temperature Sensor NTC Thermistor MF72-SCN8D-15 8ohm 15mm 3



SOCAY High Accuracy Temperature Sensor NTC Thermistor MF72-SCN8D-15 8ohm 15mm 4







Packaging Introduction:



Part Number Quantity (pcs/bag)
MF72-SCN8D-15 250(Llong/Lshort)





More product choices:

SOCAY High Accuracy Temperature Sensor NTC Thermistor MF72-SCN8D-15 8ohm 15mm 5



SOCAY High Accuracy Temperature Sensor NTC Thermistor MF72-SCN8D-15 8ohm 15mm 6

SOCAY High Accuracy Temperature Sensor NTC Thermistor MF72-SCN8D-15 8ohm 15mm 7

SOCAY High Accuracy Temperature Sensor NTC Thermistor MF72-SCN8D-15 8ohm 15mm 8



Dependability:



SOCAY High Accuracy Temperature Sensor NTC Thermistor MF72-SCN8D-15 8ohm 15mm 9





Product Represent:

SOCAY High Accuracy Temperature Sensor NTC Thermistor MF72-SCN8D-15 8ohm 15mm 10SOCAY High Accuracy Temperature Sensor NTC Thermistor MF72-SCN8D-15 8ohm 15mm 11SOCAY High Accuracy Temperature Sensor NTC Thermistor MF72-SCN8D-15 8ohm 15mm 12







Company Profile:

SOCAY High Accuracy Temperature Sensor NTC Thermistor MF72-SCN8D-15 8ohm 15mm 13

SOCAY High Accuracy Temperature Sensor NTC Thermistor MF72-SCN8D-15 8ohm 15mm 14SOCAY High Accuracy Temperature Sensor NTC Thermistor MF72-SCN8D-15 8ohm 15mm 15SOCAY High Accuracy Temperature Sensor NTC Thermistor MF72-SCN8D-15 8ohm 15mm 16SOCAY High Accuracy Temperature Sensor NTC Thermistor MF72-SCN8D-15 8ohm 15mm 17SOCAY High Accuracy Temperature Sensor NTC Thermistor MF72-SCN8D-15 8ohm 15mm 18SOCAY High Accuracy Temperature Sensor NTC Thermistor MF72-SCN8D-15 8ohm 15mm 19

Shipment Service :



SOCAY High Accuracy Temperature Sensor NTC Thermistor MF72-SCN8D-15 8ohm 15mm 20









FAQ

SOCAY High Accuracy Temperature Sensor NTC Thermistor MF72-SCN8D-15 8ohm 15mm 21



Contact Imformation:

SOCAY High Accuracy Temperature Sensor NTC Thermistor MF72-SCN8D-15 8ohm 15mm 22
