Radial Lead Resin Coated NTC Thermistor MF72-SCN10D-11 3A Imax Wide Resistance Range

1000PCS / 500PCS
MOQ
Negotiable
Price
Radial Lead Resin Coated NTC Thermistor MF72-SCN10D-11 3A Imax Wide Resistance Range
Features Gallery Product Description Request A Quote
Features
Specifications
Product Name: NTC Thermistor
Package Type: Ф11mm
R25: 10Ω
Imax: 3A
Resistance Under Load: 275mΩ
δ: 14mW/℃
τ: 47 Secs.
Storage Temperature Range: -10 To +40 ℃
Highlight:

Radial Lead NTC Thermistor

,

Resin Coated NTC Thermistor

,

NTC 10D-11
Basic Infomation
Place of Origin: Shenzhen, Guangdong, China
Brand Name: SOCAY
Certification: UL,REACH,RoHS,ISO
Model Number: MF72-SCN10D-11
Document: Product Brochure PDF
Payment & Shipping Terms
Delivery Time: 5-8 work days
Product Description

SOCAY Radial Lead Resin Coated NTC Thermistor MF72-SCN10D-11 Operating Temperature Range -40~+200℃



DATASHEET:  MF72-SCN10D-11_v2105.1.pdf



Part Number

Resistance

at 25℃

±20%

Max.

Permissible

Working

Current

Resistance

under Load

(mΩ)

Dissipation

Factor

Thermal

Time

Constant

Maximum permissible capacitance

@240Vac

  R25(Ω) Imax(A) (mΩ) δ(mW/℃) τ(Sec.) C(μF)
MF72-SCN10D-11 10 3 275 14 47 220






Radial Lead Resin Coated NTC Thermistor MF72-SCN10D-11 3A Imax Wide Resistance Range 0

Classification


DIP:5Φ~25Φ

Current:0.3A~20A

PPTC:Positive temperature coefficient

NTC:Negative temperature coefficient,
collectively referred to as thermistors.



Applications:

u Switch mode power supply

u Electric motor

u Transformer

u Adapter

u Projector

u Halogen lamp

u LED driver circuit





Radial Lead Resin Coated NTC Thermistor MF72-SCN10D-11 3A Imax Wide Resistance Range 1





Radial Lead Resin Coated NTC Thermistor MF72-SCN10D-11 3A Imax Wide Resistance Range 2







Radial Lead Resin Coated NTC Thermistor MF72-SCN10D-11 3A Imax Wide Resistance Range 3



Part Number Type of L Quantity (pcs/bag)
MF72-SCN10D-11 Lshort 1000
  Llong 500







Item Test conditions / Methods Test Result

Tensile Strength

of Terminals

 Fasten body with a Load Applied to each lead 3.0Kg for 1sec. No break out and damage

Bending

Strength of

Terminals

 Fixed body hand 1.0kg on one terminal bend 90 then back again oppsite. No break out and damage
Solder Ability When the Lead wire was dipped into bath 0f 235 ± 5 ℃ for 3 seconds after immersion in 25% rosin flux the solder ability ratio of lead wire surface should more than 95%. More than 95% solder ability
Temp. Cycle Test

(-40℃×→+25℃×3min) × 5Cycles

(-85℃×→+25℃×3min) × 5Cycles

 ∣ΔR/R∣≤ ±20 %
Humidity Test 45℃ 95%RH×1000 hours ∣ΔR/R∣≤ ±20 %
Load Life 6 AMP×1000 hours ∣ΔR/R∣≤ ±20 %
Insulation Test DC 700V R≥500MΩ



We are manufacturer and supplier with over 20 years experience for passive components as below
1- ESD
2- TVS Diodes
3- PPTC Resettable Fuse
4- Gas Discharge Tube
5- NTC Themistor
6- Varistor,etc.
