Home /Products/NTC Thermistor/SOCAY NTC Thermistor MF72-SCN3D-15 3ohm 15mm High Accuracy Temperature Sensor

SOCAY NTC Thermistor MF72-SCN3D-15 3ohm 15mm High Accuracy Temperature Sensor

2000PCS / 1000PCS
MOQ
Negotiable
Price
SOCAY NTC Thermistor MF72-SCN3D-15 3ohm 15mm High Accuracy Temperature Sensor
Features Gallery Product Description Request A Quote
Features
Specifications
Resistance At 25℃ ±20%: 3Ω
Max. Permissible Working Current: 7A
Resistance Under Load (mΩ): 75mΩ
Dissipation Factor(mW/℃）: 18mW/℃
Thermal Time Constant（Sec.)_）: 76Sec.
Maximum Permissible Capacitance @240Vac(uF): 470uF
Body Size: 15mm
Operating Temperature Range: -40~+200℃
Storage Temperature Range: -10 To +40 ℃
Highlight:

NTC Thermistor MF72-SCN3D-15

,

3ohm NTC Thermistor

,

MF72-SCN3D-15
Basic Infomation
Place of Origin: Shenzhen,Guangdong,China
Brand Name: SOCAY
Certification: UL,REACH,ROHS,ISO
Model Number: MF72-SCN3D-15
Document: Product Brochure PDF
Payment & Shipping Terms
Packaging Details: Bulk
Delivery Time: 5-7 days
Payment Terms: T/T, Western Union, MoneyGram,
Supply Ability: 250,000PCS Per Month
Product Description

SOCAY High Accuracy Temperature Sensor NTC Thermistor MF72-SCN3D-15 3ohm 15mm



DATASHEET:  MF72-SCN3D-15_v2105.1.pdf







SOCAY NTC Thermistor MF72-SCN3D-15 3ohm 15mm High Accuracy Temperature Sensor 0

SOCAY NTC Thermistor MF72-SCN3D-15 3ohm 15mm High Accuracy Temperature Sensor 1

Part Namin Code:

SOCAY NTC Thermistor MF72-SCN3D-15 3ohm 15mm High Accuracy Temperature Sensor 2

(1) MF72: MF72 Series.

(2) SCN: Socay NTC.

(3) 3D: Zero Power Resistance at 25℃(R25): 3=3Ω.

(4) Body Size: 15=Ф15mm.



Electrical Arguments:



Part Number Resistance
at 25℃
±20%		 Max. Permissible
Working
Current		 Resistance
under Load
(mΩ)		 Dissipation
Factor		 Thermal
Time
Constant		 Maximum
permissible
capacitance
@240Vac
R25(Ω) Imax(A) (mΩ) δ(mW/℃) τ(Sec.) C(uF)
MF72-SCN3D-15 3 7 75 18 78 470



Maximum Power Rating(Pmax):



SOCAY NTC Thermistor MF72-SCN3D-15 3ohm 15mm High Accuracy Temperature Sensor 3

Product Appearance :

SOCAY NTC Thermistor MF72-SCN3D-15 3ohm 15mm High Accuracy Temperature Sensor 4



SOCAY NTC Thermistor MF72-SCN3D-15 3ohm 15mm High Accuracy Temperature Sensor 5







Packaging Introduction:



Part Number Quantity (pcs/bag)
MF72-SCN3D-15 250(Llong/Lshort)





More product choices:

SOCAY NTC Thermistor MF72-SCN3D-15 3ohm 15mm High Accuracy Temperature Sensor 6



SOCAY NTC Thermistor MF72-SCN3D-15 3ohm 15mm High Accuracy Temperature Sensor 7

SOCAY NTC Thermistor MF72-SCN3D-15 3ohm 15mm High Accuracy Temperature Sensor 8

SOCAY NTC Thermistor MF72-SCN3D-15 3ohm 15mm High Accuracy Temperature Sensor 9



Dependability:



SOCAY NTC Thermistor MF72-SCN3D-15 3ohm 15mm High Accuracy Temperature Sensor 10





Product Represent:

SOCAY NTC Thermistor MF72-SCN3D-15 3ohm 15mm High Accuracy Temperature Sensor 11SOCAY NTC Thermistor MF72-SCN3D-15 3ohm 15mm High Accuracy Temperature Sensor 12SOCAY NTC Thermistor MF72-SCN3D-15 3ohm 15mm High Accuracy Temperature Sensor 13







Company Profile:

SOCAY NTC Thermistor MF72-SCN3D-15 3ohm 15mm High Accuracy Temperature Sensor 14

SOCAY NTC Thermistor MF72-SCN3D-15 3ohm 15mm High Accuracy Temperature Sensor 15SOCAY NTC Thermistor MF72-SCN3D-15 3ohm 15mm High Accuracy Temperature Sensor 16SOCAY NTC Thermistor MF72-SCN3D-15 3ohm 15mm High Accuracy Temperature Sensor 17SOCAY NTC Thermistor MF72-SCN3D-15 3ohm 15mm High Accuracy Temperature Sensor 18SOCAY NTC Thermistor MF72-SCN3D-15 3ohm 15mm High Accuracy Temperature Sensor 19SOCAY NTC Thermistor MF72-SCN3D-15 3ohm 15mm High Accuracy Temperature Sensor 20

Shipment Service :



SOCAY NTC Thermistor MF72-SCN3D-15 3ohm 15mm High Accuracy Temperature Sensor 21









FAQ

SOCAY NTC Thermistor MF72-SCN3D-15 3ohm 15mm High Accuracy Temperature Sensor 22



Contact Imformation:

SOCAY NTC Thermistor MF72-SCN3D-15 3ohm 15mm High Accuracy Temperature Sensor 23



Tag:

NTC Power Thermistor

Negative Temperature Coefficient Thermistor

NTC Thermistor MF72-SCN3D-15
