SOCAY Temperature Senso Power NTC Thermistor MF72-SCN3D-11 3Ω 11mm Wide Resistance Range

1000
MOQ
USD0.01-0.25/piece
Price
SOCAY Temperature Senso Power NTC Thermistor MF72-SCN3D-11 3Ω 11mm Wide Resistance Range
Features Gallery Product Description Request A Quote
Features
Specifications
Product Name: NTC Thermistor
Package Type: Ф11mm
NTC R25: 3Ω
Imax（A）: 5A
Resistance Under Load: 126mΩ
δ（mW/℃）: 13mW/℃
τ（Secs.）: 43Secs.
Capacitance: 220μF
Basic Infomation
Place of Origin: Shenzhen,Guangdong,China
Brand Name: SOCAY
Certification: UL,REACH,ROHS,ISO
Model Number: MF72-SCN3D-11
Document: Product Brochure PDF
Payment & Shipping Terms
Packaging Details: Bulk
Delivery Time: 5-8 work days
Payment Terms: T/T, Western Union, MoneyGram
Product Description

SOCAY Power NTC Thermistor MF72-SCN3D-11 3Ω 11mm Wide Resistance Range


DATASHEET:MF72-SCN3D-11_v2105.1.pdf



Features: Applications: Storage Conditions of Products:
  1. RoHS & Halogen Free (HF) compliant.
  2. Radial lead resin coated.
  3. Body size: Ф11mm.
  4. Wide resistance range.
  5. High power rating.
  6. Operating temperature range: -40~+200℃.
  7. Cost effective.


  1. Electric motor.
  2. Switch mode power supply.
  3. Adapter.
  4. Transformer.
  5. Projector.
  6. LED driver circuit.
  7. Halogen lamp.
  1. Period of Storage: 1 year.
  2. Storage Conditions:

Storage Temperature: -10℃ ~ +40℃.
Relative Humidity:≤ 75%RH.
Keep away from corrosive atmosphere and sunlight.





Part Number Code



MF72  SCN  3D  -  11

(1)       (2)     (3)      (4)


(1) MF72: MF72 Series.
(2) SCN: Socay NTC.
(3) 3D: Zero Power Resistance at 25℃(R25):
(4) Body Size: 11=Ф11mm





Electrical Characteristics
  1. Resistance at 25℃ ±20%: R3(Ω)
  2. Resistance under Load (mΩ): 126mΩ
  3. Max. Permissible Working Current: 5A
  4. Thermal Time Constant τ(Sec.):45Sec.
  5. Dissipation Factor δ(mW/℃): 13mW/℃
  6. permissible capacitance @240Vac C(uF): 220uF



Maximum Power Rating(Pmax)



SOCAY Temperature Senso Power NTC Thermistor MF72-SCN3D-11 3Ω 11mm Wide Resistance Range 0





MF72-SCN3D-11 Quantity (pcs/bag)
L short 1000
L long 500



SOCAY Temperature Senso Power NTC Thermistor MF72-SCN3D-11 3Ω 11mm Wide Resistance Range 1
