Home /Products/NTC Thermistor/SOCAY Power NTC Thermistor MF72-SCN10D-20 10Ω 20mm Imax Wide Resistance Range

SOCAY Power NTC Thermistor MF72-SCN10D-20 10Ω 20mm Imax Wide Resistance Range

2000PCS
MOQ
Negotiable
Price
SOCAY Power NTC Thermistor MF72-SCN10D-20 10Ω 20mm Imax Wide Resistance Range
Features Gallery Product Description Request A Quote
Features
Specifications
Product Name: NTC Thermistor
Package Type: Ф20mm
NTC R25: 10Ω
Imax（A）: 16A
Resistance Under Load: 194mΩ
δ（W/℃）: 23m
τ（Secs.）: 118Secs.
Capacitance: 560μF
Basic Infomation
Place of Origin: Shenzhen, Guangdong, China
Brand Name: SOCAY
Certification: UL,REACH,RoHS,ISO
Model Number: MF72-SCN10D-9
Document: Product Brochure PDF
Payment & Shipping Terms
Delivery Time: 5-8 work days
Product Description

SOCAY Power NTC Thermistor MF72-SCN10D-20 10Ω 20mm Imax Wide Resistance Range


DATASHEET: MF72-SCN10D-20_v2106.1.pdf



Features RoHS & Halogen Free (HF) compl
Body size: Ф20mm
Radial lead resin coate
High power ratin
Wide resistance range
Cost effective
Operating temperature range: -40~+200℃
Agency recognition: UL /cUL/RoHS

Recommended Applications Switch mode power supply
Electric motor
Transformer
Adapter
Projector
Halogen lam
LED driver circui

Storage Conditions of Products

Storage Conditions:
Storage Temperature: -10℃ ~ +40℃. Relative Humidity:≤ 75%RH. Keep away from corrosive atmo


Period of Storage: 1 year
Electrical characteristics:
Part Number Resistance
at 25℃
±20%		 Max. Permissible
Working
Current		 Resistance
under Load
(mΩ)		 Dissipation
Factor		 Thermal
Time
Constant		 Maximum
permissible
capacitance
@240Vac
R25(Ω) Imax(A) (mΩ) δ(mW/℃) τ(Sec.) C(uF)
MF72-SCN10D-9 10 16 194 23 118 560

Part No. Code:

SOCAY Power NTC Thermistor MF72-SCN10D-20 10Ω 20mm Imax Wide Resistance Range 0



(1) MF72: MF72 Series.

(2) SCN: Socay NTC.

(3) 2.5D: Zero Power Resistance at 25℃(R25): 10=10Ω.

(4) Body Size: 20=Ф20mm.



Maximum Power Rating(Pmax)



SOCAY Power NTC Thermistor MF72-SCN10D-20 10Ω 20mm Imax Wide Resistance Range 1



Dimensions and Structure (Unit: mm)



SOCAY Power NTC Thermistor MF72-SCN10D-20 10Ω 20mm Imax Wide Resistance Range 2



D max T max P max F H Lshort / Llong d Type
22 7 3 10±0.5 -- 7±1/20±1 1 S
22 7 3 10±0.5 27.5±1 4±1/20±1 1 K/V/D

Packing:

Part Number Type of L Quantity (pcs/bag)
MF72-SCN10D-20 Lshort 100
  Llong 100







Dependability​:

SOCAY Power NTC Thermistor MF72-SCN10D-20 10Ω 20mm Imax Wide Resistance Range 3

Product Display





SOCAY Power NTC Thermistor MF72-SCN10D-20 10Ω 20mm Imax Wide Resistance Range 4SOCAY Power NTC Thermistor MF72-SCN10D-20 10Ω 20mm Imax Wide Resistance Range 5SOCAY Power NTC Thermistor MF72-SCN10D-20 10Ω 20mm Imax Wide Resistance Range 6







Company Profile:

We are a manufacturer and supplier with over 20 years of experience in electronic components, as shown below,
1- ESD
2- TVS Diodes
3- PPTC Resettable Fuse
4- Gas Discharge Tube
5- NTC Themistor
6- Varistor,etc.

SOCAY Power NTC Thermistor MF72-SCN10D-20 10Ω 20mm Imax Wide Resistance Range 7SOCAY Power NTC Thermistor MF72-SCN10D-20 10Ω 20mm Imax Wide Resistance Range 8
SOCAY Power NTC Thermistor MF72-SCN10D-20 10Ω 20mm Imax Wide Resistance Range 9SOCAY Power NTC Thermistor MF72-SCN10D-20 10Ω 20mm Imax Wide Resistance Range 10
SOCAY Power NTC Thermistor MF72-SCN10D-20 10Ω 20mm Imax Wide Resistance Range 11
SOCAY Power NTC Thermistor MF72-SCN10D-20 10Ω 20mm Imax Wide Resistance Range 12SOCAY Power NTC Thermistor MF72-SCN10D-20 10Ω 20mm Imax Wide Resistance Range 13SOCAY Power NTC Thermistor MF72-SCN10D-20 10Ω 20mm Imax Wide Resistance Range 14SOCAY Power NTC Thermistor MF72-SCN10D-20 10Ω 20mm Imax Wide Resistance Range 15



FAQ



Q: May we get some samples?

A: Of course,samples are available.

Q: What is product lead time?
For GDT, TVS, and ESD, the lead time will 1-2 weeks. For TSS, MOV, MLV, NTC, and PPTC, the lead time 2-3 weeks. According your specific requirements, we will further confirm the accurate lead time.


Q: Do you support customization?
A: Of course, We do.
