SOCAY Power NTC Thermistor MF72-SCN10D-5 10Ω Imax Wide Resistance Range
DATASHEET: MF72-SCN10D-5.pdf
Features:
RoHS & Halogen Free (HF) compliant
Body size: Ф5mm
Radial lead resin coated
High power rating
Wide resistance range
Cost effectiv
Operating temperature range: -40~+200℃
Certificate: UL /cUL/RoHS
Utilize:
Switch mode power supply
Power operated
Transformer
Adapter
Projector
Halogen lamp
LED driver circuit
Product storage conditions:
Storage Conditions:
Storage Temperature: -10℃ ~ +40℃.
Relative Humidity: ≤ 75%RH.
Keep away from corrosive atmosphere and sunlight.
Period of Storage: 1 year
Electrical characteristics:
| Part No. |
Resistance
at 25℃
±20%
|
Max.
Permissible
Working
Current
|
Resistance
under Load
(mΩ)
|
Dissipation
Factor
|
Thermal
Time
Constant
|
Maximum permissible capacitance
@240Vac
|
| |
R25(Ω) |
Imax(A) |
(mΩ) |
δ(mW/℃) |
τ(Sec.) |
C(μF) |
| MF72-SCN2.5D-13 |
10 |
0.7 |
771 |
6 |
20 |
47 |
Part No. Code:
(1) MF72: MF72 Series.
(2) SCN: Socay NTC.
(3) 2.5D: Zero Power Resistance at 25℃(R25): 10=10Ω.
(4) Body Size: 5=Ф5mm.
Maximum Power
Dimensions and Structure (Unit: mm)
| D max |
T max |
P max |
F |
H |
Lshort / Llong |
d |
Type |
| 6 |
4 |
3 |
5±0.5 |
-- |
7±1/20±1 |
0.55 |
S |
| 6 |
4 |
3 |
5±0.5 |
10±1 |
4±1/20±1 |
0.55 |
K/V/D |
Packing:
| Part Number |
Type of L |
Quantity (pcs/bag) |
| MF72-SCN10D-5 |
Lshort |
2000 |
| |
Llong |
1000 |
Dependability:
