Home /Products/NTC Thermistor/SOCAY Power NTC Thermistor MF72-SCN2.5D-13 2.5Ω Imax Wide Resistance Range

SOCAY Power NTC Thermistor MF72-SCN2.5D-13 2.5Ω Imax Wide Resistance Range

1000PCS

MOQ

Negotiable

Price

SOCAY Power NTC Thermistor MF72-SCN2.5D-13 2.5Ω Imax Wide Resistance Range

Features Gallery Product Description Request A Quote

Features

Specifications

Product Name: NTC Thermistor

Package Type: Ф13mm

NTC R25: 2.5Ω

Imax: 6A

Resistance Under Load: 88mΩ

δ: 13mW/℃

τ: 60 Secs.

Capacitance: 330μF

Basic Infomation

Place of Origin: Shenzhen, Guangdong, China

Brand Name: SOCAY

Certification: UL,REACH,RoHS,ISO

Model Number: MF72-SCN2.5D-13

Document: Product Brochure PDF

Payment & Shipping Terms

Delivery Time: 5-8 work days

Gallery

SOCAY Power NTC Thermistor MF72-SCN2.5D-13 2.5Ω Imax Wide Resistance Range

Product Description

SOCAY Power NTC Thermistor MF72-SCN2.5D-13 2.5Ω Imax Wide Resistance Range

DATASHEET: MF72-SCN2.5D-13_v2105.1.pdf

lectrical Characteristics

Part Number

Resistance

at 25℃

±20%

Max.

Permissible

Working

Current

Resistance

under Load

(mΩ)

Dissipation

Factor

Thermal

Time

Constant

Maximum permissible capacitance

@240Vac

R25(Ω)

Imax(A)

(mΩ)

δ(mW/℃)

τ(Sec.)

C(μF)

MF72-SCN2.5D-13

2.5

6

88

13

60

330

Classification

 RoHS & Halogen Free (HF) compliant

 Body size: Ф13mm

 Radial lead resin coated

 High power rating

 Wide resistance range

 Cost effective

 Operating temperature range: -40~+200℃

 Agency recognition: UL /cUL/RoHS

Applications:

 Switch mode power supply

 Electric motor

 Transformer

 Adapter

 Projector

 Halogen lamp

 LED driver circuit

Storage Conditions of Products:

 Storage Conditions:

Storage Temperature: -10℃ ~ +40℃.

Relative Humidity: ≤ 75%RH.

Keep away from corrosive atmosphere and sunlight.

 Period of Storage: 1 year

Part Number Code

SOCAY Power NTC Thermistor MF72-SCN2.5D-13 2.5Ω Imax Wide Resistance Range 0

(1) MF72: MF72 Series.

(2) SCN: Socay NTC.

(3) 2.5D: Zero Power Resistance at 25℃(R25): 2.5=2.5Ω.

(4) Body Size: 13=Ф13mm.

SOCAY Power NTC Thermistor MF72-SCN2.5D-13 2.5Ω Imax Wide Resistance Range 1

Structure and Dimensions (Unit: mm)

SOCAY Power NTC Thermistor MF72-SCN2.5D-13 2.5Ω Imax Wide Resistance Range 2

Packing Specifiction

Part Number	Type of L	Quantity (pcs/bag)
MF72-SCN10D-11	Lshort	250
	Llong	250

Reliability

Item	Test conditions / Methods	Test Result
Tensile Strength of Terminals	Fasten body with a Load Applied to each lead 3.0Kg for 1sec.	No break out and damage
Bending Strength of Terminals	Fixed body hand 1.0kg on one terminal bend 90 then back again oppsite.	No break out and damage
Solder Ability	When the Lead wire was dipped into bath 0f 235 ± 5 ℃ for 3 seconds after immersion in 25% rosin flux the solder ability ratio of lead wire surface should more than 95%.	More than 95% solder ability
Temp. Cycle Test	(-40℃×→+25℃×3min) × 5Cycles (-85℃×→+25℃×3min) × 5Cycles	∣ΔR/R∣≤ ±20 %
Humidity Test	45℃ 95%RH×1000 hours	∣ΔR/R∣≤ ±20 %
Load Life	6 AMP×1000 hours	∣ΔR/R∣≤ ±20 %
Insulation Test	DC 700V	R≥500MΩ

Company Profile

We are manufacturer and supplier with over 20 years experience for passive components as below

1- ESD

2- TVS Diodes

3- PPTC Resettable Fuse

4- Gas Discharge Tube

5- NTC Themistor

6- Varistor,etc.

SOCAY Power NTC Thermistor MF72-SCN2.5D-13 2.5Ω Imax Wide Resistance Range 3

SOCAY Power NTC Thermistor MF72-SCN2.5D-13 2.5Ω Imax Wide Resistance Range 4

SOCAY Power NTC Thermistor MF72-SCN2.5D-13 2.5Ω Imax Wide Resistance Range 5

SOCAY Power NTC Thermistor MF72-SCN2.5D-13 2.5Ω Imax Wide Resistance Range 6

SOCAY Power NTC Thermistor MF72-SCN2.5D-13 2.5Ω Imax Wide Resistance Range 7

SOCAY Power NTC Thermistor MF72-SCN2.5D-13 2.5Ω Imax Wide Resistance Range 8

FAQ

Q: May we get some samples?

A: Of course,samples are available.

Q: What is product lead time?
A: For GDT,TVS and ESD,lead time will take 1-2 weeks.For TSS,MOV,MLV,NTC,and PPTC,lead time will take 2-3 weeks.Accurate lead timewill be further confirmed when we know your specific requirement.

Q: Do you support customization?
A: Yes,we do.

Please feel free to contact us if you have any question.
