High Power Rating NTC Thermistor MF72-SCN3D-9 Working Current 4A

1000PCS / 500PCS

MOQ

Negotiable

Price

High Power Rating NTC Thermistor MF72-SCN3D-9 Working Current 4A

Features Gallery Product Description Request A Quote

Features

Specifications

Product Name: NTC Thermistor

Package Type: Ф9mm

R25: 3Ω

Imax: 4A

Resistance Under Load: 120mΩ

δ: 11mW/℃

τ: 35 Secs.

C: 110μF

Storage Temperature Range: -10 To +40 ℃

Highlight:

NTC Thermistor 4A

,

High Power Rating NTC Thermistor

,

NTC 3D-9

Basic Infomation

Place of Origin: Shenzhen, Guangdong, China

Brand Name: SOCAY

Certification: UL,REACH,RoHS,ISO

Model Number: MF72-SCN3D-9

Document: Product Brochure PDF

Payment & Shipping Terms

Delivery Time: 5-8 work days

Gallery

High Power Rating NTC Thermistor MF72-SCN3D-9 Working Current 4A

Product Description

9D Series NTC Thermistor MF72-SCN3D-9 Working Current 4A Dissipation Factor 11mW/℃

DATASHEET: MF72-SCN3D-9_v2105.1.pdf

Part Number

Resistance

at 25℃

±20%

Max.

Permissible

Working

Current

Resistance

under Load

(mΩ)

Dissipation

Factor

Thermal

Time

Constant

Maximum permissible capacitance

@240Vac

R₂₅(Ω)

I_max(A)

(mΩ)

δ(mW/℃)

τ(Sec.)

C(μF)

MF72-SCN3D-9

3

4

120

11

35

110

High Power Rating NTC Thermistor MF72-SCN3D-9 Working Current 4A 0

Features:

RoHS & Halogen Free (HF) compliant
Body size: φ9mm
Radial lead resin coated
High power rating
Wide resistance range
Cost effective
Operating temperature range: -40~+200℃
Agency recognition: UL /cUL/RoHS

Applications:

u Switch mode power supply

u Electric motor

u Transformer

u Adapter

u Projector

u Halogen lamp

u LED driver circuit

Storage Conditions of Products:

u Storage Conditions:

Storage Temperature: -10℃ ~ +40℃.

Relative Humidity: ≤ 75%RH.

Keep away from corrosive atmosphere and sunlight.

u Period of Storage: 1 year.

High Power Rating NTC Thermistor MF72-SCN3D-9 Working Current 4A 1

High Power Rating NTC Thermistor MF72-SCN3D-9 Working Current 4A 2

High Power Rating NTC Thermistor MF72-SCN3D-9 Working Current 4A 3

Part Number	Type of L	Quantity (pcs/bag)
MF72-SCN3D-9	L_short	1000
	L_long	500

Item	Test conditions / Methods	Test Result
Tensile Strength of Terminals	Fasten body with a Load Applied to each lead 3.0Kg for 1sec.	No break out and damage
Bending Strength of Terminals	Fixed body hand 1.0kg on one terminal bend 90 then back again oppsite.	No break out and damage
Solder Ability	When the Lead wire was dipped into bath 0f 235 ± 5 ℃ for 3 seconds after immersion in 25% rosin flux the solder ability ratio of lead wire surface should more than 95%.	More than 95% solder ability
Temp. Cycle Test	(-40℃×→+25℃×3min) × 5Cycles (-85℃×→+25℃×3min) × 5Cycles	∣ΔR/R∣≤ ±20 %
Humidity Test	45℃ 95%RH×1000 hours	∣ΔR/R∣≤ ±20 %
Load Life	6 AMP×1000 hours	∣ΔR/R∣≤ ±20 %
Insulation Test	DC 700V	R≥500MΩ
