Name: SC3E8-600H Gas Discharge Tube GDT Classical Components For Protecting Circuit
Brand: SOCAY
SKU: SC3E8-600H
Rating: 5 (109 reviews)

Features Gallery Product Description Request A Quote

Features

Specifications

Other Name: Gdt Arrester

Lenght: φ8*10mm

Material: Cecramic

DC Spark-over Voltage @100V/μs: 600V±20%

Foot: 3 Pin Electrode

Max. Spark-over Impulse Voltage @100V/μs: 500V

Max. Spark-over Impulse Voltage @1KV/μs: 600V

Arc Voltage @1A: 15V

Nom. Impulse Discharge Current: 10KA

Max. Impulse Discharge Current: 20KA

Highlight:

SC3E8-600H Gas Discharge Tube

Circuit Gas Discharge Tube

GDT Classical Components

Basic Infomation

Place of Origin: Shenzhen, Guangdong, China

Brand Name: SOCAY

Certification: UL,REACH,RoHS,ISO

Model Number: SC3E8-600H

Document: Product Brochure PDF

Payment & Shipping Terms

Delivery Time: 2-3weeks

Supply Ability: 1000000

Gallery

SC3E8-600H Gas Discharge Tube GDT Classical Components For Protecting Circuit

Product Description

Gas Discharge Tube SC3E8-600H, Classical Components for Protecting the Circuit

DATASHEET: SC3E8_v2308.1.pdf

Part Number	Marking	DC Spark-over Voltage	Maximum Impulse Spark-over Voltage		Minimum Insulation Resistance	Maximum Capacitance	Arc Voltage	Service Life
		DC Spark-over Voltage	Maximum Impulse Spark-over Voltage			Maximum Capacitance	Arc Voltage	Nominal Impulse Discharge Current	Max Impulse Discharge Current	Nominal Alternating Discharge Current	Impulse Life
		@100V/S	@100V/μs	@1KV/μs		@1MHz	@1A	@8/20μs ⁴⁾ ±5 times	@8/20μs⁴⁾ 1 time	@50Hz⁴⁾ 1 Sec 10 times	@10/1000μs ⁴⁾ 300 times
SC3E8-75HM SC3E8-75HMF SC3E8-75HP SC3E8-75H	SOCAY 75H	75V±20%	＜500V	＜600V	1 GΩ (at 50V)	＜1.5pF	~25V	20KA	25KA	20A	200A
SC3E8-90HM SC3E8-90HMF SC3E8-90HP SC3E8-90H	SOCAY 90H	90V±20%	＜500V	＜600V	1 GΩ (at 50V)	＜1.5pF	~25V	20KA	25KA	20A	200A
SC3E8-150HM SC3E8-150HMF SC3E8-150HP SC3E8-150H	SOCAY 150H	150V±20%	＜500V	＜600V	1 GΩ (at 50V)	＜1.5pF	~25V	20KA	25KA	20A	200A
SC3E8-230HM SC3E8-230HMF SC3E8-230HP SC3E8-230H	SOCAY 230H	230V±20%	＜600V	＜700V	1 GΩ (at 100V)	＜1.5pF	~25V	20KA	25KA	20A	200A
SC3E8-250HM SC3E8-250HMF SC3E8-250HP SC3E8-250H	SOCAY 250H	250V±20%	＜600V	＜700V	1 GΩ (at 100V)	＜1.5pF	~25V	20KA	25KA	20A	200A
SC3E8-300HM SC3E8-300HMF SC3E8-300HP SC3E8-300H	SOCAY 300H	300V±20%	＜800V	＜900V	1 GΩ (at 100V)	＜1.5pF	~25V	20KA	25KA	20A	200A
SC3E8-350HM SC3E8-350HMF SC3E8-350HP SC3E8-350H	SOCAY 350H	350V±20%	＜800V	＜900V	1 GΩ (at 100V)	＜1.5pF	~25V	20KA	25KA	20A	200A
SC3E8-420HM SC3E8-420HMF SC3E8-420HP SC3E8-420H	SOCAY 420H	420V±20%	＜900V	＜1000V	1 GΩ (at 100V)	＜1.5pF	~25V	20KA	25KA	20A	200A
SC3E8-470HM SC3E8-470HMF SC3E8-470HP SC3E8-470H	SOCAY 470H	470V±20%	＜900V	＜1000V	1 GΩ (at 100V)	＜1.5pF	~25V	20KA	25KA	20A	200A
SC3E8-600HM SC3E8-600HMF SC3E8-600HP SC3E8-600H	SOCAY 600H	600V±20%	＜1100V	＜1200V	1 GΩ (at 100V)	＜1.5pF	~25V	20KA	25KA	20A	200A
SC3E8-800HM SC3E8-800HMF SC3E8-800HP SC3E8-800H	SOCAY 800H	800V±20%	＜1200V	＜1400V	1 GΩ (at 100V)	＜1.5pF	~25V	20KA	25KA	20A	200A
Notes: 1). Terms in accordance with ITU-T K.12 and GB/T 9043-2008 2). At delivery AQL 0.65 level Ⅱ, DIN ISO 2859 3). Tip or ring electrode to center electrode 4). Total current through center electrode, half value through tip respectively ring electrode

GDT Classification

Surface Mount(package size):1206,1210,1812
DIP:2-Electrode,3-Electrode

DC Voltage:75V~800V

High DC Voltage :1000V~6000V

Current:0.5KA~20KA

Response Time≤100NS,SWITH components.

Applications:

Industrial power supply,

communication power supply,

inverter power supply,

UPS uninterrupted power supply,

regulated power supply,

driving power supply,

switching power supply, power module

FAQ

Q: May we get some samples?

A: Of course,samples are available.

Q: What is product lead time?

A: For GDT,TVS and ESD,lead time will take 2-3 weeks.For TSS,MOV,MLV,NTC,and PPTC,lead time will take 3-4weeks.Accurate lead time will be further confirmed when we know your specific requirement.

Q: Do you support customization?

A: Yes,we do.
